IATF16949 Certified Dual Sided PCB Prototype Black Mask 110v-240v
IATF16949 BGA Dual Sided PCB Prototyping Printed Circuit Assy 110v-240v
Product Specifications
| Attribute | Value |
|---|---|
| Impedance Tolerance | +/-5% |
| Mask | black |
| Silkscreen | White |
| Input | 110v-240v |
| Raw Material | Fr - 4 |
| Certs | UL, ISO9001/14001, RoHS, SGS, IATF16949 |
| Display | Digital LCD Display |
| Gender | Pin header |
2 Layer Black Small BGA Double Sided PCB Circuit Board Prototype
Basic Information
Layer: 2
Size: 3*2CM
Surface finish: HASL Lead free
Thickness: 1.6mm
Copper weight: 35UM
Color: Black solder mask
Size: 3*2CM
Surface finish: HASL Lead free
Thickness: 1.6mm
Copper weight: 35UM
Color: Black solder mask
Key Features and Advantages
- Increased circuit density: Copper traces and components on both sides allow for more compact electronic designs.
- Enhanced functionality: Supports complex circuitry with through-hole and surface-mount components.
- Improved signal integrity: Additional copper layer reduces electromagnetic interference and minimizes noise.
- Design flexibility: Efficient space utilization with components on both sides and jumper wire connections.
- Cost-effective: Requires fewer manufacturing processes than multi-layer PCBs.
Design Considerations
- Careful component placement to minimize signal interference
- Strategic signal routing to maintain integrity and proper impedance
- Effective power and ground plane allocation
- Thermal management solutions for heat dissipation
- Design for manufacturability guidelines
- Accessible test points for debugging
- EMI mitigation practices
Common Applications
- Consumer electronics (smartphones, tablets, TVs)
- Industrial control systems and automation
- Automotive electronics and ECUs
- Medical devices and diagnostic equipment
- Telecommunications infrastructure
- Industrial power supplies and control panels
- LED lighting systems
