FR4 Double Sided PCB 2 Layer 1.6mm Thickness RoHS Compliant

FR4 Double Sided PCB 2 Layer 1.6mm Thickness RoHS Compliant

  • Vurgulamak

    Jlcpcb metal pcb board

    ,

    multimeter metal pcb board

    ,

    Jlcpcb multimeter circuit board

  • Marş
    Fr4
  • Katman sayısı
    2 Kat
  • ROHS uyumlu
    Evet
  • Bakırlık
    1 oz
  • Kalınlık
    1.6 mm
  • Mintracpace
    0.2 mm
  • Karakteristik hizmet
    ODM/OEM/PCBA
  • Renk
    yeşil, mavi, sarı
  • Place of Origin
    Shenzhen,China
  • Marka adı
    ONESEINE
  • Sertifika
    ISO9001,ISO14001
  • Model Number
    ONE-102
  • Minimum Order Quantity
    1pcs
  • Fiyat
    USD0.1-1000
  • Packaging Details
    Vacuun bag
  • Delivery Time
    5-8 working days
  • Payment Terms
    T/T, Western Union
  • Supply Ability
    1000000000pcs/mon

FR4 Double Sided PCB 2 Layer 1.6mm Thickness RoHS Compliant

Jlcpcb Printed Metal PCB Board Double Sided Multimeter Circuit Board Assembly
Product Specifications
Attribute Value
Material FR4
Layer Count 2 Layer
Rohs Compliant Yes
Copper Thickness 1oz
Thickness 1.6mm
Min Trace Space 0.2mm
Characteristic Service ODM/OEM/PCBA
Color green, blue, yellow
Basic Information
Hot Jlcpcb 2 Layer Printed Circuit Board Double Sided PCB Assembly
Layer: 2
Size: 2*2CM
Surface finish: HASL Lead free
Thickness: 1.2mm
Copper weight: 1.5OZ outer
Color: Yellow solder mask
Design Considerations for Double-Sided PCBs
Working with double-sided PCBs requires attention to several key factors:
  • Component Placement: Careful arrangement to minimize interference and ensure proper clearance
  • Signal Routing: Strategic planning to avoid crosstalk and maintain signal integrity
  • Power and Ground Planes: Effective allocation to reduce noise and improve stability
  • Thermal Management: Implementation of heat sinks, thermal vias, and copper pours
  • Design for Manufacturability: Proper pad sizes, solder mask openings, and trace spacing
  • Testing and Debugging: Accessibility considerations for test points
  • EMI Mitigation: Proper grounding and shielding techniques
Key Features and Advantages
  • Increased circuit density for complex designs
  • Enhanced functionality with through-hole and surface-mount components
  • Improved signal integrity with dedicated ground/power planes
  • Greater design flexibility with components on both sides
  • Cost-effective compared to multi-layer PCBs
Common Applications
  • Consumer electronics (smartphones, tablets, TVs)
  • Industrial control systems and automation
  • Automotive electronics (ECUs, infotainment)
  • Medical devices and diagnostic equipment
  • Telecommunications infrastructure
  • Industrial power supplies and control panels
  • LED lighting systems
