IPC-6012B HASL Quick Turn PCB Board Assembly Customized
Product Specifications
Attribute |
Value |
Product |
High Level PCB |
Attributes |
HASL Lead Free PCB, Components, Assembly 1.2mm, Turnkey PCB Assembly, Low-Volume PCB Assembly, Prototype PCB Assembly, PCB PCBA, Quick Quote, SMT Stencil, PCB Assembly Services |
Services |
PCB PCBA Manufacturer |
Enclosure Assembly |
2 Assembly Lines |
Inspection Standard |
IPC-A-600H/IPC-6012B |
Test |
Flying Probe Test |
Component |
Infineon, TI, NXP |
High Level Customized Prototype FR4 PCB Assembly
Basic Information
- Material: FR4
- Layer: 4
- Board thickness: 1.2mm
- Surface finish: HASL lead free
- Copper weight: 1OZ
- Solder mask: Blue
- Silk screen: White
- Production: PCB+Components+Assembly
- Delivery time: 15 days for 10 sets
Comprehensive PCB Assembly Services
- PCB Assembly: SMT, THT/DIP, BGA, COB soldering
- PCB Manufacture: 1-24 layers, Buried & Blind via PCB, Impedance PCB, High frequency PCB, FR-4, Aluminium PCB
- PCBA Testing Jigs: PMMA, Automated & Manual Tooling
- PCB Design: We transform your ideas or schematic diagrams into complete PCB & PCBA designs
- PCB Copy & Clone: We can replicate existing PCBs and provide Gerber and BOM files
Quality Assurance & Support
- Comprehensive document audit to prevent PCB Gerber and BOM errors
- Quality component replacement suggestions with cost optimization
- Engineering support for testing and mass production preparation
- Secure NDA agreements to protect your designs
- Optimal shipping method recommendations
Frequently Asked Questions
Q1: How do you ensure PCB quality?
A1: All PCBs undergo 100% testing including Flying Probe Test, E-test, and AOI inspection.
Q2: What are your lead times?
A2: Samples require 7-10 working days; mass production takes 10-20 working days, depending on files and quantity.
Q3: Can you offer competitive pricing?
A3: Yes, our engineers optimize designs to minimize material costs while maintaining quality.
Q4: What files are required?
A4: PCB-only orders need Gerber files; PCBA requires both Gerber files and BOM.
Q5: Is my design information secure?
A5: Absolutely. We strictly maintain confidentiality and can sign NDAs.
Q6: Can I visit your facility?
A6: Yes, we welcome visits to our Shenzhen facility.
Q7: Can I get samples?
A7: Yes, we provide samples (with cost) and refund 50% when order exceeds 20 sqm.
PCB Assembly Process Overview
Component Procurement
Sourcing electronic components based on specifications, availability, and cost.
PCB Fabrication
Manufacturing bare boards using etching/printing techniques to create copper traces and connection pads.
Component Placement
- SMD: Automated pick-and-place systems position components with high precision
- THT: Component leads inserted into pre-drilled holes (automated or manual)
- Mixed Technology: Strategic combination of SMD and THT components
Soldering
- Reflow Soldering: Primary method for SMDs using controlled heating
- Wave Soldering: For THT components using molten solder waves
Inspection & Testing
- Automated Optical Inspection (AOI)
- X-ray examination
- Functional testing
- Visual checks for defects and alignment
Final Integration
Approved PCBs proceed to product integration including enclosures, connectors, and cabling.
